プロダクト細部
起源の場所: チャンシャ、湖南、中国
ブランド名: Elacera
証明: ISO9001-2015
モデル番号: 陶磁器の袖の並べられた管
支払及び船積みの言葉
最小注文数量: 交渉可能
価格: 交渉可能
パッケージの詳細: 木製のケースまたは鉄のラックに詰められています
受渡し時間: 25-45ワークダス
支払条件: T/T
供給の能力: 100,000㎡/年
カスタマイズ: |
リクエストに応じて利用可能 |
表地: |
鋼鉄 |
色: |
白またはカスタマイズされた |
耐摩耗性: |
高い |
サイズ範囲: |
DN50-DN1200 |
サイズ: |
1/2インチ～24インチ |
応用: |
腐食 的 な 環境 |
標準: |
GB,ASTM,ASME,DIN,JIS |
認証: |
ISO 9001,ISO 14001 |
圧力定格: |
最大10バー |
カスタマイズ: |
リクエストに応じて利用可能 |
表地: |
鋼鉄 |
色: |
白またはカスタマイズされた |
耐摩耗性: |
高い |
サイズ範囲: |
DN50-DN1200 |
サイズ: |
1/2インチ～24インチ |
応用: |
腐食 的 な 環境 |
標準: |
GB,ASTM,ASME,DIN,JIS |
認証: |
ISO 9001,ISO 14001 |
圧力定格: |
最大10バー |
Product Description
In industries where abrasion, high temperature, and corrosion occur simultaneously, traditional metal components often fail quickly. Silicon carbide ceramic components are increasingly used to replace metal parts due to their exceptional hardness, wear resistance, and thermal stability.
Typical silicon carbide ceramic products include wear-resistant pipes, ceramic nozzles, cyclone liners, elbows, and custom structural components. These products are widely used in slurry conveying, dust removal, spray cooling, and material handling systems.
Key benefits
Typical Silicon Carbide Ceramic Products
Core Advantages of Alumina Nozzles
High Cost-Effectiveness: At only 30%-60% of the price of silicon carbide ceramic nozzles, it offers the best cost-effectiveness for medium-to-low-wear, ambient-temperature conditions such as cement production line dust removal and port spraying. - Good Formability: It can be manufactured into complex, custom-shaped spray structures, such as fan, cone, and spiral spray patterns, to suit diverse atomization needs.
Established Application System: With mature production processes and high-quality stability, it has established comprehensive selection and application solutions for small and medium-sized industrial applications.
| Performance Dimensions | Silicon Carbide Ceramic Nozzle | Aluminum Oxide Nozzle | Advantages |
| Mohs hardness | 9.2 (second only to diamond) | 8.5-9.0 (increases with increasing aluminum oxide content) | Silicon carbide is harder and more scratch-resistant. |
| Wear Resistance (Relative Value) | 1.0 (Baseline Value) | 0.4-0.7 (92% Aluminum Oxide: 0.4, 99% Aluminum Oxide: 0.7) | Silicon carbide has significantly better wear resistance than aluminum oxide and a longer service life. |
| High-temperature resistance | Long-term operating temperature: 1200°C, short-term operating temperature: 1600°C | Long-term operating temperature: 800-1100°C (the higher the content, the higher the temperature). | Long-term operating temperature: 800-1100°C (the higher the content, the higher the temperature). |
| Corrosion Resistance | Resistant to strong acids, strong bases, and molten metals, but not resistant to hydrofluoric acid. | Resistant to neutral and weak acids and bases, but susceptible to damage in highly corrosive environments. | Silicon carbide offers comprehensive corrosion resistance and is suitable for complex corrosion conditions. |
| Impact Resistance | Flexural Strength 400-500 MPa, Medium Toughness | Flexural Strength 300-450 MPa (Toughness Slightly Lower with High Alumina Content) | Silicon Carbide Has Slightly Better Impact Resistance and Greater Resistance to Operating Vibration |
| Atomization Performance | Flow channel smoothness Ra ≤ 0.8 μm, atomization uniformity ≥ 95% | Flow channel smoothness Ra ≤ 1.2 μm, atomization uniformity 90%-95% | Silicon carbide atomization is more uniform, resulting in higher fluid delivery efficiency |
Nozzle spray pattern, Special-shaped wear parts
